Thermal camera, white ethernet camera, 320x240 (chinese camera) ID:188

From Protospace Wiki
Jump to navigation Jump to search

← Back to tools we have

Type thermal camera
Make/Model 320x240
Serial number
Original owner elad.orbach
Loan status donated to protospace
Arrival date 11.23.24
Location electronics room
Functional status working
Usage permissions everyone
Certification none
Wiki-ID 188
Label 1.0" 1.5" 2.0"


Specs

Temperature Range: 82° to 108°F (28° to 42°C)

Detector: Uncooled Focal Plane Array

Resolution: ≥ 384x288 IR

Thermal Sensitivity: <50mK

Spectral Range: 8μm ~ 14μm

Measurement Distance: 16-1/2 ft.

Lens Type: 33.8° x 44.3°

Image Frame Rate: 25 Hz

Alarms: Visual and Audio

Video Output: Gigabit Ethernet Interface

Camera Dimensions: 9-3/4" x 4-1/2" x 6-1/4"; 3.3-lbs.

Focus: 8mm

Pixel Size: 17μm

Power Supply: DC12V, <1.5A; Blackbody 220V

Usage

TBD

Troubleshooting

Connect the camera to the protospace pc ethernet input

Connect the camera to its power supply (12v) and turn it on

On the desktop open the thermal_cam folder -> mtam… -> mta

Password Is: 123

everything else is explained in the manual

Documentation

https://docs.telavivmakers.space/_media/tamiwiki/projects/695800m.pdf
