Bandsaw, metal, horizontal (Westward UE-712) ID:165

From Protospace Wiki
Jump to navigation Jump to search
       ← Back to tools we have
Type Westward UE-712 Horizontal-Vertical Band Saw
Make/Model Westward UE-712
Serial number ??
Original owner Protospace
Loan status None
Arrival date 2022-10-22
Location Between metal bay and welding area
Functional status Functional
Usage permissions ??
Certification ??
Wiki-ID 165
Label 1.0" 1.5" 2.0"


Do not expect to find a functional blade in this tool, they don't last more than a couple weeks due to abuse.

Supply your own sharps; purchasing details are below.

Specifications

  • Blade size: 3/4" x 0.032" x 93" - available at Princess Auto (best value?), Busy Bee and KMS.
  • Blade speeds: 86/132/178/260 FPM
  • Cutting capacity 7" x 12" (depends on shape and miter angle, see manual for details or try)
  • Horsepower: 3/4HP (560W)

Manual

Manual (different model but same saw, goes by a few names/brands: JET, Acra, etc.)

Features

Built-in coolant system

Automatic shut-off

Operation

If you're ever doing/getting a demo of this tool, fill in this section on how it works!

(pages 17/18 of the manual effectively cover this)

How to:

  • not hurt your self/arms/eyes...
  • not killing sawblades
  • set up and hold material
  • adjusting cutting pressure
  • using coolant effectively
  • setting up for vertical operation
  • cleaning and maintenance

Maintenance

Oil Change

Drain and refill gear box oil after first 90 days of operation. Thereafter, change every six months. Use 90W oil.

Oil Change
Date Completed By

Coolant Check

Check coolant every 3 months, <<need more info on what to do if coolant level is low ex. what type of coolant it takes>>

Coolant
Date Action Taken Completed By

Log

Oct 22nd 2022 - installed
