Sander, drum (General International 15-250 M1) ID:106
Jump to navigation
Jump to search
 | |
| Type | Drum Sander |
| Make/Model | General International 15-250 M1 |
| Serial number | 382107 |
| Original owner | |
| Loan status | |
| Arrival date | 2017? |
| Location | Woodworking shop |
| Functional status | Needs Power and Dust collection |
| Usage permissions | |
| Certification | Basic woodworking safety course |
| Wiki-ID | 106 |
| Label | 1.0" 1.5" 2.0" |
Usage Notes
- Requires training
- Please take gentle light passes
- Refer to page 16-17 on the manual for sanding belts
Specs
- 220V@15A, 3HP, 1Ph
- Maximum sanding width: 24” (610 mm)
- Maximum sanding thickness: 5” (127 mm)
- Minimum sanding thickness: 1/4” (6 mm)
- Minimum sanding length: 5” (127 mm)
- Drum diameter: 5” (127 mm)
- Drum speed: 1550 RPM
- Feeding speed (variable): 3 TO 20 FPM (0.93 to 6.2 M/MIN) (VARIABLE)
